Helix HEXCA12AB Mustang II Tubular Lower Control Arm Set

Helix Mustang II Tubular Lower Control Arms are the Grade A LCA that your hot rod needs for maximum performance! These control arms are a fully assembled ready-to-install left and right set that are a direct replacement for stock Mustang II LCAs and designed to accept coil over or air shocks without modification or fabrication. The Helix lower control arm assembly features precision fabricated TIG welded construction and 1 inch O.D. aircraft quality tubular steel design with full .120 wall for maximum strength and durability. This makes for a lighter weight yet much stronger LCA than the original stock arm that will endure a far higher stress load than the OEM design. Complete left and right assembly includes 2 ea. 5/8-11 x 12 hex bolts (cross shaft), nylon locking nuts and large 5/8 washers, built-in polyurethane no-squeak bushings w/ steel sleeves, screw-in ball joint with urethane dust boot & grease fitting, castle nut w/ cotter pin, and castle nut/ball joint spacers (2 ea. x 2). This lower control arm assembly is stock design and ready to drop in immediately out of the box. For all of your suspension needs, Helix deliver the winning edge for maximum performance when it really counts! Stay ahead of the pack with Helix Suspension.

• Fully Assembled :: Yes
• Construction :: High Quality Steel
• Application :: Mustang II IFS
• Type :: Tubular
• Tube Finish :: Plain Painted Surface
• Cross Shaft Finish :: Plain Steel
• TIG Welded :: Yes
• Screw In Ball Joint :: Yes
• Grease Fitting Included :: Yes
• Urethane Dust Boot :: Yes
• Fully Assembled :: Yes
• Adjustable :: No
• Tube O.D. :: 1 in. (25 mm)
• Full .120 Wall Tubing
• Center to Center Length :: 13? (33.0 cm)
• (Ball Joint Shaft Center to Cross Shaft Eye Center)
• Overall Width :: 10.5? (26.7 cm)
• Overall Length :: 14.75? (37.46 cm)
• Cross Shaft O.D. :: 5/8? (16 mm)
• Quantity :: Set
• Left Side LCA :: 1
• Right Side LCA :: 1
• Hardware Included :: Yes
• Pin and Gusset Included :: No
• Springs Included :: No
• Air Shock Included :: No
• Castle Nut :: 2
• Cotter Pin :: 2
• Castle Nut Spacer :: 2(2)
• Urethane Bushings :: 4
• Steel Sleeves :: 4
• 5/8-11 x 12? Hex Bolt :: 2
• 5/8-11 Nylon Lock Nut :: 2
• 5/8 Large Flat Plain Washer :: 4
• Precision Engineered
• Years of Testing & Design
• Direct Fit For Helix IFS Kits
• Designed In USA:: Yes
• Limited Lifetime Warranty
